Petrol generator Genergy Perryridge-S 5500W 230V manual start
Manual winding boot
2480178 | |
1703 |
Download
More info
Petrol generator Genergy Perryridge-S 5500W 230V manual start
Gasoline generator with the new engine EURO-PRO Genergy SGB V, efficient and highly reliable, ensuring easy and smooth start in any condition. Manual starter rope.
- Smart Display. Notifies the user of maintenance work required at all times. Also, it is shown in screen voltage, frequency and hours.
- Automatic shutdown for lack of oil, protects the motor from serious damage in case of no or low level of lubricating oil.
- Rack enclosure with integrated wheels (not sobreexceden of the frame, facilitating linear product storage or rental stores).
- Alternator winding all copper of high quality. Longer life, greater startability of inductive material, the greater tolerance to overcharging or over temperature, infinitely more resistant to environmental etch.
- Electronic voltage regulation ensures a correct and stable voltage at all times.
- Overload protection by thermal circuit breaker.
- 30mA differential protection against leakage current.
- 2x16A + 1x32A outlets (IP67).
- Genergy total guarantee 2 years including labor, transportation and spare parts *.
* 1 year warranty for the machines invoiced to companies, cooperatives, partnerships or other legal status different from that of individual consumers.
Technical characteristics:
Stabilization system / Stabilizer system | Electronic "SVR" / Electronic "SVR" |
Voltage - Frequency / Voltage - Frequency | 230V - 50Hz |
Maximum AC 230V / Maximum (S2 5min) | 5500W |
Nominal AC 230V / Rated (COP) | 5000W |
AC 400V Maximum / Maximum (S2 5min) | - |
AC 400V Nominal / Rated (COP) | - |
Type by number of phases / phase class Number | Phase / single-phase |
Power Factor / Power factor | one |
Model Engine / Engine model | SGB420PRO |
Displacement / Displacement | 420cc |
Engine / Engine type | Gasoline, 4 times OHV air cooler / petrol 4 stroke OHV air cooling |
Sound pressure level LpA average 7mts (Ralenti-nominal) 7mts average sound pressure level LpA (Idle-rated) | 67dB - 74dB |
Sound power level LwA guaranteed Guaranteed sound power level LwA | 97dB |
Type start / Starting type | Manual / Recoil |
Fuel tank capacity / Fuel tank capacity | 6L |
25-50-75% consumption to the load / 25-50-75% load Consumption | one. 5 L / H - 1.8L / H - 2.3L / H |
Autonomy 25-50-75% load / Long run time 25-50-75% load | 4.0H - 3.3h - 2.6h |
Capacity and grade of oil / oil grade and capacity | 1.1L - SAE10W40 |
Insulation level / Insulation grade | F |
Insulation class according to quality / Quality insulation class | TO |
Class according to performance / Performace class | G1 |
Standard / Standard | ISO 8528-13: 2016 |
Kit / Wheel kit | Integrated with 10 "wheels / Integrated With 10" wheels |
Dimensions / Dimensions | 787x623x640mm |
Weight / Weight | 89kg |
video 360
Buy Petrol generator Genergy Perryridge-S 5500W 230V manual start
-
